| Ideal Use | For end of ledger/header or post structures designed to provide support underneath the joist, rafter or beam |
|---|---|
 | Approved for use with Strong-Drive #9 SD Connector Screws |
| Material | Zinc Galvanized (G90) Steel |
product chart
| Product Code | Min. Heel Height | Coating / Material | Gauge | Width | Height | (B) Base Depth | Min. Order | UPC | |
|---|---|---|---|---|---|---|---|---|---|
| LUS24Z | 2-5/8" | ZMAX | 18 | 1-9/16" | 3-1/8" | 1-3/4" | 100 | 044315804304 | |
| LUS26Z | 4-1/4" | ZMAX | 18 | 1-9/16" | 4-3/4" | 1-3/4" | 100 | 044315734403 | |
| LUS28Z | 4-3/16" | ZMAX | 18 | 1-9/16" | 6-5/8" | 1-3/4" | 50 | 044315268700 | |
| LUS210 | 4-1/4" | Zinc Galvanized (G90) | 18 | 1-9/16" | 7-13/16" | 1-3/4" | 50 | 044315684005 | |
| LUS210Z | 4-1/4" | ZMAX | 18 | 1-9/16" | 7-13/16" | 1-3/4" | 25 | 044315000607 | |
| LUS26-2Z | 2-1/4" | ZMAX | 18 | 3-1/8" | 4-7/8" | 2" | 25 | 044315271908 | |
| LUS28-2Z | 4-9/16" | ZMAX | 18 | 3-1/8" | 7" | 2" | 25 | 044315572302 | |
| LUS210-2Z | 6-7/16" | ZMAX | 18 | 3-1/8" | 9" | 2" | 25 | 044315250804 | |
| LUS28-3Z | 6-13/16" | ZMAX | 18 | 4-15/16" | 7-1/4" | 4" | 15 | 707392970309 | |
| LUS210-3Z | 6-1/4" | ZMAX | 18 | 4-5/8" | 6-1/4" | 2" | 25 | 707392185505 |
LOAD VALUES
| Product Code | Fasteners | Allowable Loads | ||||||||
| Face | Joist | DF/SP | SPF/HF | |||||||
| Uplift (160) | Floor (100) | Snow (115) | Roof (125) | Uplift (160) | Floor (100) | Snow (115) | Roof (125) | |||
| LU24L | 4 x SD9112R100 | 2 x SD9112R100 | 340 | 685 | 725 | 725 | 290 | 450 | 515 | 560 |
| LU26L | 6 x SD9112R100 | 4 x SD9112R100 | 915 | 1025 | 1030 | 1030 | 715 | 670 | 775 | 840 |
| LU28L | 8 x SD9112R100 | 6 x SD9112R100 | 995 | 1370 | 1380 | 1380 | 855 | 895 | 1030 | 1120 |
| LU210L | 10 x SD9112R100 | 6 x SD9112R100 | 1150 | 1710 | 1965 | 2010 | 990 | 1120 | 1290 | 1400 |
